ADR 2019 Preview: nuovi numeri per gli "articoli"
Con l'ADR 2019 è introdotta la nuova sezione 2.5.1 con 12 nuove rubriche n.a.s. relative agli "articoli".
Documento completo in allegato Riservato Abbonati
Ai fini della nuova sezione 2.5.1, per "articolo" si intendono macchinari, apparecchi o altri dispositivi contenenti una o più merci pericolose (o loro residui) che sono parte integrante dell'articolo, necessarie al suo funzionamento e che non possono essere rimosse ai fini del trasporto. Un imballaggio interno non deve essere un articolo.
Previste nuove Istruzioni di imballaggio P006 e LP03
__________
2.1.5 Classification of articles as articles containing dangerous goods, n.o.s.
NOTE: For articles which do not have a proper shipping name, other than UN Nos. 3537 to 3548, and which contain only dangerous goods within the permitted limited quantity ECE/TRANS/WP.15/240 8 amounts specified in Column (7a) of Table A of Chapter 3.2, see UN No. 3363 and special provisions 301 and 672 of Chapter 3.3
| (1) |
(2) |
(3a) |
(3b) |
| 3537 |
ARTICLES CONTAINING FLAMMABLE GAS, N.O.S. |
2 |
F |
| 3538 |
ARTICLES CONTAINING NON-FLAMMABLE, NON TOXIC GAS, N.O.S. |
2 |
6A |
| 3539 |
ARTICLES CONTAINING TOXIC GAS, N.O.S. |
2 |
6T |
| 3540 |
ARTICLES CONTAINING FLAMMABLE LIQUID, N.O.S. |
3 |
F3 |
| 3541 |
ARTICLES CONTAINING FLAMMABLE SOLID, N.O.S. |
4.1 |
F4 |
| 3542 |
ARTICLES CONTAINING A SUBSTANCE LIABLE TO SPONTANEOUS COMBUSTION, N.O.S. |
4.2 |
S6 |
| 3543 |
ARTICLES CONTAINING A SUBSTANCE WHICH IN CONTACT WITH WATER EMITS FLAMMABLE GASES, N.O.S. |
4.3 |
W3 |
| 3544 |
ARTICLES CONTAINING OXIDIZING SUBSTANCE, N.O.S. |
5.1 |
O3 |
| 3545 |
ARTICLES CONTAINING ORGANIC PEROXIDE, N.O.S. |
5.2 |
P1 or P2 |
| 3546 |
ARTICLES CONTAINING TOXIC SUBSTANCE, N.O.S. |
6.1 |
T10 |
| 3547 |
ARTICLES CONTAINING CORROSIVE SUBSTANCE, N.O.S. |
8 |
C11 |
| 3548 |
ARTICLES CONTAINING MISCELLANEOUS DANGEROUS GOODS, N.O.S. |
9 |
M11 |
Special provisions for the labelling of articles
5.2.2.1.12 Special provisions for the labelling of articles containing dangerous goods carried as UN Nos. 3537, 3538, 3539, 3540, 3541, 3542, 3543, 3544, 3545, 3546, 3547 and 3548.
5.2.2.1.12.1 Packages containing articles or articles carried unpackaged shall bear labels according to 5.2.2.1 reflecting the hazards established according to 2.1.5, except that for ECE/TRANS/WP.15/240 52 articles that in addition contain lithium batteries, a lithium battery mark or a label conforming to model No. 9A is not required.
5.2.2.1.12.2 When it is required to ensure articles containing liquid dangerous goods remain in their intended orientation, orientation arrows meeting 5.2.1.10.1 shall be affixed and visible on at least two opposite vertical sides of the package or of the unpackaged article where possible, with the arrows pointing in the correct upright direction.”.
| P006 PACKING INSTRUCTION P006 |
| This instruction applies to UN Nos. 3537 to 3548. |
(1) The following packagings are authorized, provided that the general provisions of 4.1.1 and 4.1.3 are met:
Drums (1A2, 1B2, 1N2, 1H2, 1D, 1G);
Boxes (4A, 4B, 4N, 4C1, 4C2, 4D, 4F, 4G, 4H1, 4H2);
Jerricans (3A2, 3B2, 3H2)
Packagings shall conform to the packing group II performance level.
(2) In addition, for robust articles the following packagings are authorized:
Strong outer packagings constructed of suitable material and of adequate strength and design in relation to the packaging capacity and its intended use. The packagings shall meet the provisions of 4.1.1.1, 4.1.1.2, 4.1.1.8 and
4.1.3 in order to achieve a level of protection that is at least equivalent to that provided by Chapter 6.1. Articles may be carried unpackaged or on pallets when the dangerous goods are afforded equivalent protection by the article in which they are contained.
(3) Additionally, the following conditions shall be met:
(a) Receptacles within articles containing liquids or solids shall be constructed of suitable materials and secured in the article in such a way that, under normal conditions of carriage, they cannot break, be punctured or leak their contents into the article itself or the outer packaging;
(b) Receptacles containing liquids with closures shall be packed with their closures correctly oriented. The receptacles shall in addition conform to the internal pressure test provisions of 6.1.5.5;
(c) Receptacles that are liable to break or be punctured easily, such as those made of glass, porcelain or stoneware or of certain plastics materials shall be properly secured. Any leakage of the contents shall not
substantially impair the protective properties of the article or of the outer packaging;
(d) Receptacles within articles containing gases shall meet the requirements of Section 4.1.6 and Chapter 6.2
as appropriate or be capable of providing an equivalent level of protection as packing instructions P200 or P208;
(e) Where there is no receptacle within the article, the article shall fully enclose the dangerous substances and prevent their release under normal conditions of carriage.
(4) Articles shall be packed to prevent movement and inadvertent operation during normal conditions of carriage. |
| LP03 PACKING INSTRUCTION LP03 |
| This instruction applies to UN Nos. 3537 to 3548. |
(1) The following large packagings are authorized, provided that the general provisions of 4.1.1 and 4.1.3 are met:
Rigid large packagings conforming to the packing group II performance level made of:
steel (50A);
aluminium (50B);
metal other than steel or aluminium (50N);
rigid plastics (50H);
natural wood (50C);
plywood (50D);
reconstituted wood (50F);
rigid fibreboard (50G).
(2) Additionally, the following conditions shall be met:
(a) Receptacles within articles containing liquids or solids shall be constructed of suitable materials and secured in the article in such a way that, under normal conditions of carriage, they cannot break, be punctured or leak their contents into the article itself or the outer packaging;
(b) Receptacles containing liquids with closures shall be packed with their closures correctly oriented. The receptacles shall in addition conform to the internal pressure test provisions of 6.1.5.5;
(c) Receptacles that are liable to break or be punctured easily, such as those made of glass, porcelain or stoneware or of certain plastics materials shall be properly secured. Any leakage of the contents shall not substantially impair the protective properties of the article or of the outer packaging;
(d) Receptacles within articles containing gases shall meet the requirements of Section 4.1.6 and Chapter 6.2 as appropriate or be capable of providing an equivalent level of protection as packing instructions P200 or P208; and
(e) Where there is no receptacle within the article, the article shall fully enclose the dangerous substances and prevent their release under normal conditions of carriage.
(3) Articles shall be packed to prevent movement and inadvertent operation during normal conditions of carriage. |
...
segue
