ISO 7000 / IEC 60417 Graphical symbols for use on equipment

International Electrotechnical Commission International Organization for Standardization Graphical Symbols for Use on Equipment.

The database on Graphical Symbols for Use on Equipment contains the complete set of graphical symbols included in IEC 60417 and ISO 7000.

Standards are maintained respectively by IEC/TC 3, subcommittee SC 3C and ISO/TC 145, subcommittee SC 3.

Each graphical symbol is identified by a reference number and contains a title (in English and French), a graphical representation in GIF and vectorized PDF format, and some additional data as applicable.

In allegato elenco simboli grafici codificati con didascalia (n. 4851). Nella Rev. 2025 aggiunte didascalie.
