UNI ISO 4309:2019 | Apparecchi di sollevamento - Funi
| ID 7892 | | Visite: 10757 | Documenti Riservati Normazione | Permalink: https://www.certifico.com/id/7892 |
UNI ISO 4309:2019
Apparecchi di sollevamento - Funi - Cura, manutenzione, ispezioni e scarto
Data entrata in vigore: 28 febbraio 2019
La norma stabilisce i principi generali per la cura, la manutenzione, i controlli e i criteri di scarto delle funi di acciaio in servizio sugli apparecchi di sollevamento.
Adotta: ISO 4309:2017
Sostituisce: UNI ISO 4309:2011
...
In allegato Preview ISO 4309:2017 riservata Abbonati
ISO 4309:2017 establishes general principles for the care and maintenance, and inspection and discard of steel wire ropes used on cranes and hoists. In addition to guidance on storage, handling, installation and maintenance, this document provides discard criteria for those running ropes which are subjected to multi-layer spooling, where both field experience and testing demonstrate that deterioration is significantly greater at the crossover zones on the drum than at any other section of rope in the system.
It also provides more realistic discard criteria covering decreases in rope diameter and corrosion, and gives a method for assessing the combined effect of deterioration at any position in the rope.
ISO 4309:2017 is applicable to those ropes used on the following types of cranes, the majority of which are defined in ISO 4306-1:
b) cantilever cranes (pillar jib, wall or walking); c) deck cranes; d) derrick and guy derrick cranes; e) derrick cranes with rigid bracing; f) floating cranes; g) mobile cranes; h) overhead travelling cranes; i) portal or semi-portal bridge cranes; j) portal or semi-portal cranes; k) railway cranes; l) tower cranes; m) offshore cranes, i.e. cranes mounted on a fixed structure supported by the sea bed or on a floating unit supported by buoyancy forces.a) cable and portal cable cranes;
ISO 4309:2017 applies to rope on cranes, winches and hoists used for hook, grabbing, magnet, ladle, excavator or stacking duties, whether operated manually, electrically or hydraulically.
....
Fonte: UNI
ISO
Collegati:
| Descrizione | Livello | Dimensione | Downloads | |
|---|---|---|---|---|
 |
Preview ISO 4309 2017.pdf |
836 kB | 48 |
