Arc Flash IE and Iarc Calculators / IEEE

Arc Flash IE and Iarc Calculators / IEEE 1584-2018

ID 24966 | 22.11.2025 / Attached

The excel spreadsheet files provide access to a functional Arc Flash Calculator that includes various equipment configurations (VCB, VCBB, HCB, VOA and HOA), Incident Energy and voltage ranges (IEEE 1584-2018).

- IEEE ExcelCalculator V 2.6.6 mm 08.29.2019
- IEEE ExcelCalculator V 2.6.6 M-mm 08.29.2019 - specifically for the reduced arcing current (I_arc_min) case
- Arc Flash IE and Iarc Calculators User Manual
- Arc Flash Disclaimer

As equipment’s configuration and input fields are presented, the user will be able to key entry specific data using the proper input fields and/or pull down menus provided. All variables and constants are defined. When all variables inputs have been entered, and proper equipment configuration has been selected, the Calculator will solve the equations and the answer is returned.

The Calculator function within the spreadsheets provide quick access to data analysis that could increase the productivity for the user.

Allegati

Allegati

	Descrizione	Lingua	Dimensioni	Downloads
	IEEE ExcelCalculator V 2.6.6 mm 08.29.2019	EN	1626 kB	136
	IEEE ExcelCalculator V 2.6.6 M-mm 08.29.2019	EN	1736 kB	138
	Arc Flash IE and Iarc Calculators User Manual	EN	758 kB	345
	Arc Flash Disclaimer	EN	266 kB	230
