EN 1264-X:2021 | Sistemi radianti annegati
ID 12503 | 04.01.2021 / Preview allegate
La norme EN 1264-X:2021 sono attualmente in revisione e saranno pubblicate nella nuova versione dopo la votazione finale da parte degli stati membri.
La norme EN 1264-X:2021 sono in revisione all'interno interno del WG9, gruppo di lavoro del CEN/TC 130, che a livello nazionale è seguito dalla commissione UNI/CTI 254 del Comitato Termotecnico Italiano.
Programma di lavoro CEN/TC 130
|
Project reference |
Status |
Initial Date |
Current Stage |
Next Stage |
Forecasted voting date |
|
FprEN 1264-1 (WI=00130051) Water based surface embedded heating and cooling systems - Part 1: Definitions and symbols |
Under Approval |
2018-04-23 |
2020-10-29 |
2021-01-14 |
2020-10-29 |
|
FprEN 1264-2 (WI=00130054) Water based surface embedded heating and cooling systems - Part 2: Floor heating: Methods for the determination of the thermal output using calculations and experimental tests |
Under Approval |
2018-04-23 |
2020-10-29 |
2021-01-14 |
2020-10-29 |
|
FprEN 1264-3 (WI=00130055) Water based surface embedded heating and cooling systems - Part 3: Dimensioning |
Under Approval |
2018-04-23 |
2020-10-29 |
2021-01-14 |
2020-10-29 |
|
FprEN 1264-4 (WI=00130052) Water based surface embedded heating and cooling systems - Part 4: Installation |
Under Approval |
2018-04-23 |
2020-10-29 |
2021-01-14 |
2020-10-29 |
|
FprEN 1264-5 (WI=00130053) Water based surface embedded heating and cooling systems - Part 5: Determination of the thermal output for wall and ceiling heating and for floor, wall and ceiling cooling |
Under Approval |
2018-04-23 |
2020-10-29 |
2021-01-14 |
2020-10-29 |
Principali modifiche
- Nuove tipologie (anche senza isolante): inserite nella parte 1 della norma
- Nuove definizioni (parte 1)
- Materiali e conducibilità (parte 2)
- Isolante bugnato (parte 3)
- Temperatura massima sistemi radianti a soffitto (parte 3)
- Modifiche ai contenuti sull’installazione della parte 4
- Nuove tipologie (anche senza isolante): inserite nella parte 1 della norma
- Nuove definizioni (parte 1)
- Materiali e conducibilità (parte 2)
- Isolante bugnato (parte 3)
- Temperatura massima sistemi radianti a soffitto (parte 3)
- Modifiche ai contenuti sull’installazione della parte 4
Lo scopo della norma è, pertanto, cambiato:
- La EN 1264 fornisce le linee guida per i sistemi di riscaldamento e raffrescamento annegati - installati in edifici, residenziali e non (ad esempio uffici, edifici pubblici, commerciali e industriali) e si focalizza sul tema del comfort termico.
- La EN 1264 fornisce le linee guida per i sistemi di riscaldamento e raffreddamento idronici annegati all’interno degli ambienti da riscaldare o da raffrescare. Specifica inoltre l'uso di altri fluidi termovettori al posto dell'acqua.
- La EN 1264 specifica le caratteristiche standardizzate dei prodotti - calcolando e testando la potenza termica in riscaldamento per le certificazioni. Per la progettazione, la costruzione e il funzionamento di questi sistemi, vedere EN 1264-3 e EN 1264-4 per i tipi A, B, C, D, H, I e J.
- I sistemi descritti nella EN 1264 sono montati, direttamente o con supporti di fissaggio, in aderenza alla base strutturale delle superfici dell’edificio. La norma EN 1264 non si applica ai sistemi a controsoffitto che presentano un’intercapedine che consente la circolazione dell’aria tra il sistema stesso e la struttura dell’edificio. La resa termica di questi sistemi può essere determinata secondo EN 14037 e EN 14240.
The main changes of the prEN 1264-1:2020 with respect to the previous edition are listed below:
a)Clarified the scope;
b)Improved wording, especially the term “prove method”;
c)Specified the definition of embedded heating and cooling systems;
d)Expanded the types of embedded heating and cooling systems;
e)Deleted, modified and added of several terms and definitions;
f)Updated references.
The main changes of the prEN 1264-2:2020 with respect to the previous edition are listed below:
a) Modified the title;
b) Clarified the scope;
c) Improved wording, especially the term “prove method”;
d) Modified Clause 9;
e) Deleted Clause 10 Test procedure for the determination of the effective thermal resistance of carpets and all references to this Clause;
f) Removed Figures A.9, A.10 and A.11;
g) Table A.13 Heat conductivities for materials was moved to the new Annex D and was expanded;
h) Deleted Annex B Test procedure for the determination of parameters for application in EN 15377;
i) Added new Annex C Calculation of the specific heat capacity (C-Value).
a) Modified the title;
b) Clarified the scope;
c) Improved wording, especially the term “prove method”;
d) Modified Clause 9;
e) Deleted Clause 10 Test procedure for the determination of the effective thermal resistance of carpets and all references to this Clause;
f) Removed Figures A.9, A.10 and A.11;
g) Table A.13 Heat conductivities for materials was moved to the new Annex D and was expanded;
h) Deleted Annex B Test procedure for the determination of parameters for application in EN 15377;
i) Added new Annex C Calculation of the specific heat capacity (C-Value).
The main changes of the prEN 1264-3:2020 with respect to the previous edition are listed below:
a) Clarification of the scope;
b) Improved wording, especially the term “prove method”;
c) Deleted the Note in 4.1.2.2;
d) Added new subclauses 4.1.3.1, 4.2.3.1, 4.3.3.1 and 5.2.1.1 Pressure loss;
e) Modified the maximum average surface temperature for ceiling heating systems in 4.2.1.4;
f) Replaced Figures 1 and 3 with Figures A.2 and A.3.
a) Clarification of the scope;
b) Improved wording, especially the term “prove method”;
c) Deleted the Note in 4.1.2.2;
d) Added new subclauses 4.1.3.1, 4.2.3.1, 4.3.3.1 and 5.2.1.1 Pressure loss;
e) Modified the maximum average surface temperature for ceiling heating systems in 4.2.1.4;
f) Replaced Figures 1 and 3 with Figures A.2 and A.3.
The main changes of the prEN 1264-4:2020 with respect to the previous edition are listed below:
a) Clarified the scope;
b) Improved wording, especially the term “prove method”;
c) Added a new subclause 4.1 Hydronic balancing;
d) Added a paragraph in 4.2.2.1 Supporting base;
e) Modified 4.2.2.2 Insulating layers;
f) Added a new subclause 4.2.2.4 Other layers;
g) Modified 4.2.2.9 Weight bearing layer;
h) Added a new subclause 4.2.2.9.5.4 Tubes damage;
i) Modified 4.2.3 Leak test;
j) Modified 4.2.4 Initial heat up;
k) Added a new Annex B Initial heating up protocol;
l) Added a new subclause 4.2.5 Heating up for readiness for covering;
m) Modified 4.3.3 Insulation;
n) Improved wording.
The main changes of the prEN 1264-5:2020 with respect to the previous edition are listed below:
a)Modified the title;
b)Clarified the scope;
c)Improved wording, especially the term “prove method”.
a)Modified the title;
b)Clarified the scope;
c)Improved wording, especially the term “prove method”.
Attachment .pdf files Draft prEN 1264-X:2020
Fonte: CEN
